ONKA 35mm2 PE Screw Rail Clamp Block DIN Rail Clamp 2-Wire Gray, 1010225
- Regular price
- €8,44
- Regular price
-
- Sale price
- €8,44
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
The compact rail-mounted connectors from ONKA offer great possibilities for connecting wires with different cross-sections. The transparent housing makes it easy to check the correct placement of the wires. The original ONKA quick connectors are a convenience during installation and 100% reliable when connecting. Technical parameters
Cross-section of the connected single wire up to: 35mm2
Color: Green-yellow (camouflage)
Insulating material of the main housing: polyamide (PA6.6)
Contact/bridge material: CK45 steel/copper
Torque: 1.2 Nm
Connection position: lateral
Cable strip length: 16 mm
Type of electrical connection: screw terminal
Nominal voltage: 750V
Operating temperature range: -40°C... 140°C
Mounting method: DIN rail 35 mm
Standard: EN-60947-7-1
