ONKA 1.5mm2 spring terminal block DIN rail clamp 2-wire gray, 1020002
- Regular price
- €0,64
- Regular price
-
- Sale price
- €0,64
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
Spring rail coupling / DIN rail clamp 2-wire, retractable contact, gray, ONKA, made in Turkey
The compact installation rail couplings from ONKA offer great possibilities for connecting any wire with different cross-sections. The transparent housing makes it easy to check the correct placement of the wires. The original ONKA quick couplings are convenient for installation and 100% reliable when connecting.
Technical parameters
Cross-section of the connected single wire up to: 1.5mm2
Color: gray
Insulating material of the main housing: polyamide (PA6.6)
Material contact/bridge: stainless steel/copper
Connection position: top/top
Cable strip length: 9mm
Type electrical connection: spring clamp / retractable contact
Nominal voltage: 750V
Nominal current: 17.5A
Operating temperature range from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN 35 mm mounting rail
Norm: EN-60947-7-1
